Industrial Embedded Panel PC 10.1 inch Intel Core i3 i5 i7 processor Touch Screen all in one pc Device 3G/4G/5G module gpio
Panel PC
Industrial tablet PCs are industrial control computers designed for industrial use, and their basic performance and compatibility are similar to those of commercial computers.
However, industrial tablet PCs pay more attention to stability in different environments, and require stability in harsh environments, such as dustproof, waterproof, and anti-static.
Venoen industrial tablet pc fully meets the above requirements.
However, industrial tablet PCs pay more attention to stability in different environments, and require stability in harsh environments, such as dustproof, waterproof, and anti-static.
Venoen industrial tablet pc fully meets the above requirements.
CPU:
Intel Core i5-8260U
Intel Core i5 10210U
Intel Core i7 10510U 10810U
Memory:
64G DDR4
32G DDR4
16G DDR4
8G DDR4
4G DDR4
No RAM
Storage SSD:
1TB SSD
512G SSD
256G SSD
64G SSD
32G SSD
No SSD
Storage HDD:
2TB HDD
1TB HDD
NO HDD
Size:
21.1 inch
19.1 inch
17.1 inch
15.6 inch
15.1inch
12.1 inch
10.1 inch
Quantity:
| Basic Information: | |
| CPU | lntel Core i5/i7 CPU |
| Memory | DDR4 SODIMM x2，max to 64GB ( 32GB x2 ) |
| Ethernet | 2 x GbE RJ45 Intel i211/i210AT |
| I/O | 4 x USB3.0，2 x USB2.0 |
| 2 x DB9 RS232 COM（ support RS485/RS422） | |
| 1 x HDMI | |
| 14 x GPIO（7 pin input，7 pin output | |
| 1 x Power Button | |
| 1 x 3pin phoenix DC IN，support voltage DC 9V to 36V | |
| 1 x MIC 3.5mm，1 x MIC 3.5mm | |
| 1 x ATX/AT switch | |
| onboard SIM card slot , applied for WIFI/3G/4G/5G module | |
| Storage | 1x MSATA |
| 1x M.2 NVME 2280 SSD | |
| 1x 2.5 inch HDD/SSD | |
| Expansibility | Mini-PCIe x 1 half height size，support WiFI bluetooth |
| Mini-PCIe x 1 full height size, 1x SIM card slot, support 3G/4G/5G module，WIFI bluetooth | |
| IO x 1, support LPC，USB，PCIE | |
| OS Support | Windows 10,LINUX |
| Other function | Watch dog，one key restore, non-disk booting, wake up on LAN, automatically power on after power restore |
| Power input | DC 9 ~ 36V 4-pin aerial plug |
| Construction | Fanless passive cooling |
| Material | Aluminum alloy |
| Dimension | 376.13x285.34x68.90 mm |
| Netweight | 5 Kg |
| Store Temp. | -30℃ to +70℃ |
| Working Temp. | -20℃ to +60℃ |
| RH | 10%~90% @30℃，Non-condensing |
| Package List | 1x Panel PC |
| 1x AC Adapter (AC100-240V IN, DC12V-5A Out ) | |
| 1x Power cord ( EU AU US UK type plug shipped according to buyer's address ) | |
| 1x SATA cable | |
