H4T Series Industrial Fanless Mini PC, Type-C RS232/485 COM SIM 4G
Basic information | |
CPU | Intel Core i5 10210U 4 Cores/8 Threads, Base Frequency: 1.60GHz(Max 4.20GHz) Intel Core i5 10310U 4 Cores/8 Threads, Base Frequency: 1.70GHz(Max 4.40GHz) |
Memory | 2 * DDR4 SODIMM Slot, up to 64GB Dual Channel, DDR4 260pin |
Graphics | Intel® UHD Graphics |
LAN | 2 * Intel I210/211 RJ45 Lan |
Expansion Options | 1 * M.2 2280 PCIE3.0 X4/SATA, supports NVME/SATA protocol SSD, up to 2T 1 * SATA3.0 for installing 2.5 inch HDD/SSD,up to 6GB |
WiFi | |
Module | 1 * M.2 E key (22 * 30MM) 1 * MPCIE total height (51.0mm * 30.0mm) for canbus 5G/4G slot, suitable for 42.0mm * 30.0mm30.0mm * 52.0mm |
Antenna | 4 * external antennas |
Input/output Ports | |
Rear I/O | 4 * USB3.0+4 * USB2.0 (Type-A） |
6 * DB9 COM RS 232 or (4 * DB9COM RS232+2 * RS485) | |
1 * HDMI+1 * Type-C+1 * EDP | |
2 * DB 9pin Canbus(optional) | |
6 * Com RS232(COM3/4/5/6 supports RS232/RS422/RS485) | |
1 * 12V DC In | |
1 * Power input | |
4 * Wi-Fi antennas | |
Motherboard interface | 1 * Nano SIM slot，support 3G/4G |
Others | |
Expected Life Cycle | 5 Years |
Warranty | 3 years included; 4 or 5 year options available |
Power | 19V 4.74A External Power Adapter |
Temperature | -10℃~55℃ |
Humidity | 10%-90% relative humidity |
OS | Windows 10/11, Linux, Ubuntu, Debian, Etc. |
Other | Support Watch dog . Diskless boot.PXE |
Mechanical | |
Material | Aluminum Alloy |
Dimension | 238 * 182 * 65mm |
Weight | Net 1.9kg, Gross 2.7kg |
Mounting | Wall mouting and VESA |
Package Content | |
Standard | 1 * Mini PC,1 * Power Adapter,1 * Power Cord,1 * User Manual |
Re: Yes we can. The charges for OEM service depends on the different level of customize. the process of customization is
following:
1) provide your specific requirement.
2) our design engineer draw the design draft.
3) you confirm the design draft.
4) we start produce it.
Q2. Can you print my logo on the mini computer ?
Re: Yes, it is support.
Q3. Can your device work 24h*7 days? And what about the temperature range it can operate in?
Re: Yes it can be working in 24h*7 days, working temperature range 0°C~50°C.
Q4. What is the lead time of your products?
Re: Sample order within 1~3 business days . Bulk order within 3~15 business days ( depends on order qty) ,we will test the model
to insure the quality before shipping.
Q5.What's the warranty?
Re: 1 year warranty. After expired warranty and sent back to our company, we will still try our best to repair for you without
repair cost (except change new accessories).
Q6.What are the OS do your computers support?
Re: Support Windows 7, Windows 8, Windows 10, Linux ubuntu , pfsense etc. Some model is support XP, such as C1037U,Core CPU is not
support XP.
Q7. Which models can run pfsense as a firewall?
Re: 2 or more LAN mini pc can run pfsense as a firewall. we have 2 LAN/4 LAN/6 LAN model.
