P12B Optional Intel Core i3/i5/i7 CPU fanless industrial mini pc 2.5G LAN HDMI VGA LTE WIFI IOT
P12B 4-13th
-Support Windows 7/11/10, Linux.
-Onboard newest 10nm 10th Gen Intel Core i3/i5/i7 Processor with powerful computing performance.
-Large capacity and high frequency memory improve work efficiency and give you a smooth experience.
-Support 1*VGA 1080P and 1*HDMI 4K, for 2 screens video display synchronously and asynchronously.
-Support 1*M.2 2280 NVME/PCIE3.0x4/SATA SSD+1*2.5'' SATA HDD/SSD.
-Support 2*2.5G RJ45 Lan+M.2 2230 2.4G/5G Dual band AC(AX) WiFi/Bluetooth
-Onboard newest 10nm 10th Gen Intel Core i3/i5/i7 Processor with powerful computing performance.
-Large capacity and high frequency memory improve work efficiency and give you a smooth experience.
-Support 1*VGA 1080P and 1*HDMI 4K, for 2 screens video display synchronously and asynchronously.
-Support 1*M.2 2280 NVME/PCIE3.0x4/SATA SSD+1*2.5'' SATA HDD/SSD.
-Support 2*2.5G RJ45 Lan+M.2 2230 2.4G/5G Dual band AC(AX) WiFi/Bluetooth
CPU
Memory
Storage SSD
Wireless Kit
Operating System(Os)
Quantity
| Basic information | |
| CPU | Intel Core i3 6100U/ i3 1215U |
| Intel Core i5 4200U/ i5 7200U/ i5 8250U/ i5 10210U/i5 1135G7/ i5 1235U/ i5 1335U | |
Intel Core i7 4500U/ i7 7500U/ i7 10510U/ i7 1165G7/ i7 1255U/ i7 1280P/ i7 1355U | |
| Memory | 4/5th Generation：1* DDR3L SO-DIMM ，Up to 8GB |
| 6-11th Generation : 2*DDR4 SO-DIMM, Up to 64G | |
12/13th Generation ：2*DDR5 SO-DIMM, Up to 128GB | |
| Graphics | Intel Core i5 4200U/ i7 4500U：Intel® HD Graphics 4400 |
| Intel Core i3 6100U: intel® HD Graphics 520 | |
| Intel Core i5 7200U/ i7 7500U: intel® HD Graphics 620 | |
| Intel Core i5 8250U: intel® UHD Graphics 620 | |
| Intel Core i5 10210U/ i7 10510U: Intel® UHD Graphics for 10th Gen Intel® Processors | |
| Intel Core i5 1135G7/ i7 1165G7: Intel® Iris® Xe Graphics | |
| Intel Core i5 1235U/ i7 1255U/ I5 1335U/ i7 1355U: Intel® Iris® Xe Graphics eligible | |
| Intel Core i7 1280P: Intel® Iris® Xe Graphics eligible | |
| LAN | 4th-10th Gen: 2*RJ45 intel I210 / I211 / I219-V (Gigabit Ethernet) |
| 11th-12th Gen: 2* I226-V (2.5G Ethernet) | |
| I/O | 4 * USB3.0 + 2 * USB2.0 (Type-A） |
| 1 * DC input port（9-36V） , 3-pin Phoenix terminal | |
| 1 * 3.5MM audio output,1 * 3.5mm microphone input | |
| 2 * I226-V (2.5G Ethernet) | |
| 6 * DB9 pin COM RS232 or 2 RS232+4 RS485/RS422 | |
| 1 * PS2 interface for PS2 keyboard/mouse | |
| 1 * One-click recovery Cmos button | |
| 1 * One-click restart button | |
| 1 * 2pin external switch port with 2pin Phoenix terminal as standard | |
| 1 * ATX/AT gear | |
| 1 * 16pin GPIO port, default 7 input,7 Output, 1 5V voltage output, standard 16pin Phoenix terminal | |
| 2 * Wi-Fi antennas | |
| Expansion | 1 * MPCIE half height (26.8MM*30MM), used to install WIFI module, support dual-band Bluetooth (Bluetooth version 4.0), dual- band without Bluetooth |
| 1 * MPCIE full height (51.0mm × 30.0mm), for installing 4G module /WIFI module | |
| 1 * SIM card slot | |
| OS | 4-7th Gen:Win7/10/Linux , 8th-12th Gen:Win10/Win11/Linux |
| BIOS functions | Auto Boot (Enabled by Default), Wake-on-LAN (Abnormal Shutdown), Timed Boot, Watch Dog, Disk Array (RAID0, RAID1, RAID5), PXE |
| Power | |
| Power input | 4- 8 generations: 12V 6A as standard , 10-13 generations: 19V 4.74A as standard |
| Mechanical | |
| Material | Aluminum Alloy |
| Dimension | 250 * 150 * 86mm |
| Weight | Net 2.4kg, Gross 3.3kg |
| Mounting | Wall mouting and VESA |
| Working environment | |
| Operating temperature | -20℃ to +60℃ |
